Source

Light source type: High Performance Tungsten Lamp

Base: G 9,5 special (with heat sink)

Recommended lamp type: HPL 575/240/X 575W - 240V, HPL 575/120/X 575W - 120V

Lifetime: 1.500 hours

Colour temperature: 3.050 K

Optical system

392mm parabolic aluminium reflector with high reflectivity coating

Control and programming

External Dimmer

Thermal specification

Maximum ambient temperature: 45 °C (113 °F)

Maximum surface temperature: 160 °C (320 °F)

Electrical specification and connections

Input voltage range: 120 V or 240 V, 50/60 Hz

Power consumption: 575 W

Approvals

CE Compliant

cETLus Compliant

Mechanical specification

Height: 520 mm (20.5")

Width: 531 mm (20.9")

Depth: 241 mm (9.5")

Weight: 5.3 kg (11.7 lbs)

Ingress protection rating: IP20

Rigging

Mounting points: M12 mounting for clamp or spigot

Universal operating position

Legal

picklePATT™ is a Trademark of Robe lighting s. r. o.

picklePATT™ is patented by Robe lighting s. r. o. and protected by one or more pending or issued patents
